Figure 211 Hammer Union O-Ring — Size/Union Configuration
Figure 211 Hammer Union O-Ring — Size/Union ConfigurationRequest a Quote · Drawing and sample review
Specifications & Product Information
Figure 211 Hammer Union O-Ring
Royal Way manufactures O-ring sealing elements for buyer-defined Figure 211 hammer union assemblies. Quotations are prepared from the current union reference, exact O-ring designation or dimensions, seal-pocket details, or an existing sample.
Information for quotation
- Union manufacturer, exact figure, nominal size and original seal reference
- O-ring standard and complete size designation when specified, or exact inside diameter and cross-section
- Male and female union dimensions, seal pocket, groove and clearance
- Required backup, retaining or anti-extrusion components in the assembly
- Fluid, temperature, pressure class, pressure direction and operating cycle
- Required compound and hardness when already controlled by the specification
- Required quantity, tolerances, inspection and documentation requirements
The Figure 211 designation alone does not establish O-ring size, compound, fit or service rating. Final dimensions and compound are confirmed after the complete union configuration and operating conditions are reviewed.
Request a Quote
Request an engineering quotation
Send the product or equipment reference, drawing or sample, service conditions and quantity. Royal Way will review the details and ask for any other information needed for the quotation.
Use the RFQ form for the initial requirement. Drawings, photographs and sample details can also be emailed to sales@rwoiltool.com with the product name in the subject line.
Product and dimensions
Product type, equipment model, drawing or sample, plus the critical dimensions and construction details.
Material and service
Known material or hardness, medium, temperature, pressure, movement and observed failure.
Quantity and delivery
Trial or order quantity, packing or documentation needs, destination and requested timing.
