Custom Chemical-Injection Pump Diaphragms
Royal Way manufactures molded elastomer diaphragms for buyer-defined chemical-injection and metering-pump chambers. Quotations are prepared from a dimensioned diaphragm drawing, complete chamber and actuation dimensions, an existing sample or a verified original part reference.
Information for quotation
- Pump or metering-unit manufacturer, model, series, revision and original diaphragm reference when available
- Diaphragm outside diameter, working diameter, thickness, center profile, bead, lip and sealing geometry
- Bolt-hole pattern, clamping land, chamber, backing plate, piston or actuator dimensions
- Required fabric, insert, backing or bonded construction when specified by the assembly
- Injected chemical, concentration, carrier fluid and any cleaning or flushing media
- Stroke or deflection, suction and discharge pressure, temperature, cycle rate and expected service interval
- Required compound and hardness when already specified by the buyer
- Required quantity, dimensional tolerances, inspection and documentation requirements
A pump-family or original-part reference identifies the buyer’s target only; it does not establish geometry, compound, equipment fit or service rating. Final diaphragm construction is confirmed against the complete chamber and operating conditions.
Request a Quote
Request an engineering quotation
Send the product or equipment reference, drawing or sample, service conditions and quantity. Royal Way will review the details and ask for any other information needed for the quotation.
Use the RFQ form for the initial requirement. Drawings, photographs and sample details can also be emailed to sales@rwoiltool.com with the product name in the subject line.
Product and dimensions
Product type, equipment model, drawing or sample, plus the critical dimensions and construction details.
Material and service
Known material or hardness, medium, temperature, pressure, movement and observed failure.
Quantity and delivery
Trial or order quantity, packing or documentation needs, destination and requested timing.
