Custom Aluminum-Core Oilfield Swab Cups

Royal Way manufactures custom rubber swab cups bonded to buyer-defined aluminum bushings or cores for tubing, drill-pipe and well-service configurations. Each quotation is based on the cup style, actual tubular and mandrel dimensions, core construction, bond interface and service conditions; nominal tubing size alone is not a complete specification.

Representative image: The displayed profiles show rubber cups with visible metal cores from a company-owned source. They are examples for orientation only and do not establish alloy, dimensions, bond strength, compound or application suitability.

Configurations for review

• Drawing-defined standard, undersize, single-lip, multi-lip or other cup profiles
• Custom cup outside diameter, bore, overall length, lip geometry and stack arrangement
• Buyer-defined aluminum core or bushing dimensions, internal bore and retaining features
• Specified elastomer compound, hardness, core finish and rubber-to-metal bonding interface

Information for quotation

• Nominal tubing or drill-pipe size, actual inside diameter and relevant bore range
• Tool or mandrel drawing, cup drawing, core drawing, CAD model, measured sketch or physical sample
• Cup profile, outside diameter, inside diameter, length, lip direction and critical tolerances
• Aluminum alloy, surface finish or treatment and identification requirements when controlled
• Bonding interface, undercuts, grooves, knurls or perforations when present
• Required compound or buyer performance specification when controlled
• Transported medium, sand or solids, temperature, pressure differential, travel direction and expected operating cycle
• Quantity, prototype requirements, inspection documentation, traceability and packaging requirements

Final cup geometry, core construction, alloy, surface condition, compound, bonding method, tolerances and application suitability are confirmed after the complete tool and service requirements are reviewed.

Request a quote with drawings, CAD files or sample details.
